CLB-HRP  Horizontal Wrap-Around Labeler

Features:

This type is suited for long tubes that can't stand on their bottom and good for labeling on injection tubes, small cells, or products such as pensetc. .

PLC control system match human machine interface is easy to read and operate.

Memory capacity up to 60 sets labeling parameters for fast change of production conditions.

  • Entire machine is constructed of S304 stainless steel, and aluminum alloy for rust free performance, meeting FDA standards.

Labeling speed: 0~25m/min (adjustable).

Specification:

Inside diameter of label roll 75mm.

Maximum diameter of label roll 370mm.

Power source 110V/220V, 50/60Hz.

Standard label height below 130mm.

Maximum label height 200mm.

Machine dimensions 1500(L) x650(W) x 1450(H)mm.
